VHF/UHF FM TRANSCEIVERS Submersible (1m depth for 30 minutes) IC-F50 / F60 Superior Waterproof Protection
Supports Demanding Communication
Firefighters, Police, Security, Oil industry and Public utilities. Each profession has its own unique challenges, but all have one thing in common: the need for reliable communications. Icom’s IC-F50/F60 offers a compact waterproof, MIL STD package, thats easy to use. Rain or shine, this radio keeps you in contact in nearly any environment.
JIS Grade 7 Waterproof protection
The gasket sealed waterproof housing provides superior waterproof
protection, equivalent to JIS Grade 7*.
Reliable and dependable use in harsh conditions such as rain, snow, sudden change in temperature, make the IC-F50/F60 the radio for all situations.
* 1m depth for 30 minutes.
Built-in Tone signaling
Use the built-in CTCSS, DTCS, 2-Tone and 5-Tone capability to set up your own talk groups and quiet stand-by when others are talking. You can also set up selective calls to individuals or control a repeater.
Multiple 2-Tone, Multiple 5-Tone Up to 10 2-Tone codes can be decoded on a single memory channel. This is perfect for professionals who require multiple district paging on one channel. When a matched tone is received, the following items are programmable for each code.
• Bell icon • Answer back • Stun • Beep sound • Auto transmit • Scan
Li-Ion battery pack
The large capacity 1700mAh Lithium-Ion (Li-Ion) battery pack, BP-227 provides a practical 10 hours* of operating time.
Li-Ion batteries allow flexible charging and have almost no memory effect.
* Typical operation Tx:Rx: Stand-by=5:5:90
Up to 7 programmable buttons
The [P0]–[P3], [Red] and [Up], [Down] buttons are programmable to meet specific needs. The [Red] button on the top panel can be assigned as an emergency trigger.
Alphanumeric display
The 8-character alphanumeric display shows channel, bank, tone code and scanning channel names on the display. 7 operational icons on the sub-line show various status at a glance.
Wide range coverage and large channel capacity
The IC-F50/F60 covers a wide frequency range in one version. The large capacity of 128 memory channels with 8 memory banks allows you to divide and store a variety of channels from local to wide area network channels. Both wide and narrow (25/12.5kHz) channel bandwidth is programmable to each channel.
Compact body
56(W)×97(H)×36.4(D) mm* compact body with durable, dependable construction, meets MIL standard specifications.
* 2.2(W)×3.8(H)×1.4(D) in
Built-in voice scrambler
The IC-F50/F60 has a built-in inversion type voice scrambler in all versions. When a more secure system is required, versions with a rolling type voice scrambler* equivalent to the UT-110 are available.
* Built-in, optional unit not required.
MDC 1200 Compatible
The following selective calling and ANI features are available with the built-in MDC signaling.
• PTT ID
• Radio check
• Caller ID
• Selective call
• Emergency, emergency mic monitoring
• Radio stun/revive
• 500 Aliases
• Status/message
• Call alert
Waterproof microphone
An optional waterproof speaker-microphone, HM-138 provides reliable operation, even with the radio securely on your belt.
Other features
- Built-in compander, compatible with the IC-F30G and IC-F520 series
- 8 DTMF autodial memories
- Powerful 5W output for IC-F50, 4W output for IC-F60
- Normal and priority scans
- 2 step power saver
- Optional AA alkaline battery case, BP-226 for battery back up
- Busy, repeater lockout functions
- Power ON password, and more...
SPECIFICATIONS
| GENERAL |
| Frequency range |
: |
| |
IC-F50 |
136-174 MHz |
| |
IC-F60 |
400-470 MHz |
| |
450-512 MHz (U.S.A.) |
| |
450-520 MHz (General) |
| Number of Channels |
: Max. 128 channels/ 8 banks |
| Channel spacing |
: 12.5/25kHz, 15/30kHz |
| Antenna impedance |
: 50 ohm (SMA Type) |
| Frequency error |
: ±2.5ppm |
| PLL channel step |
: |
| |
IC-F50 |
2.5/3.125Khz |
| |
IC-F60 |
5/6.25KHz |
| Power supply requirements |
: 7.2V DC |
| Current drain (approx.) |
: |
| |
Transmit |
at 5W |
1.5A (IC-F50) |
| |
|
at 4W |
1.5A (IC-F60) |
| |
|
at 1W |
0.7A (IC-F50) |
| |
|
|
0.8A (IC-F60) |
| |
Receive |
AF max. |
300mA |
| |
|
Stand-by |
85mA |
| Operating temperature range |
: –30°C to +60°C; –22°F to +140°F |
Dimensions (W x H x D)
(projections not included) |
: 56 x 97 x 36.4mm; 2.2 x 3.8 x 1.4 in. |
| Weight (approx.) |
: 280g; 9.9oz |
| |
|
| TRANSMITTER |
| Output power |
: IC-F50 |
5.0W |
| |
IC-F60 |
4.0W |
| Modulation system |
: Variable reactance frequency modulation |
| Max. frequency deviation |
: ±5kHz (wide) |
| |
±2.5kHz (narrow) |
| Modulation limiting |
: 60-100% of Max. deviation |
| Audio harmonic distortion |
: 3% typ. (AF 1kHz, 40% deviation) |
| Spurious emissions |
: 70dB Min. |
| Adjacent channel power |
: 70dB Min. (wide) |
| : |
60dB Min. (narrow) |
| FM Hum and Noise |
: 46dB typ. (wide) |
| |
40dB typ. (narrow) |
| External microphone impedance |
: 9-pin multi connector/2.2k |
| |
|
| RECEIVER |
| Sensitivity (12dB SINAD) |
: Less than 0.25 µV |
| Squelch sensitivity |
: 0.25µV typ. (at threshold) |
| Adjacent channel selectivity |
: 75dB typ. (wide) |
| : |
65dB typ. (narrow) |
| Spurious response |
: 70dB |
| Intermodulation |
: 74dB typ. |
| Hum and noise |
: 45db typ. (wide) |
| : |
40dB typ. (narrow) |
| Audio output power |
: 0.5W typ. at 10% distortion with an 8load |
| External SP connector |
: 9-pin multi connector/8 |
| |
|
| |
Applicable U.S. Military Specifications
Icom makes rugged products that meet MIL-STD requirements and strict environmental standards as follows.
| Standard |
MIL 810C |
MIL 810D |
MIL 810E |
MIL 810F |
| Method |
Procedure |
Method |
Procedure |
Method |
Procedure |
Method |
Procedure |
| Low pressure |
500.1 |
I |
500.2 |
I, II |
500.3 |
I, II |
500.4 |
I, II |
| High temp. |
501.1 |
I |
501.2 |
I, II |
501.3 |
I, II |
501.4 |
I, II |
| Low temp. |
502.1 |
I |
502.2 |
I, II |
502.3 |
I, II |
502.4-3 |
I, II |
| Temp. shock |
503.1 |
I |
503.2 |
I |
503.3 |
I |
503.4 |
I |
| Solar Radiation |
505.1 |
I |
505.2 |
I |
505.3 |
I |
505.4 |
I |
| Rain |
506.1 |
I, II |
506.2 |
I, II |
506.3 |
I, II |
506.4 |
I, III |
| Humidity |
507.1 |
I, II |
507.2 |
II, III |
507.3 |
II, III |
507.4 |
- |
| Salt fog |
509.1 |
I |
509.2 |
I |
509.3 |
I |
509.4 |
- |
| Dust |
510.1 |
I |
510.2 |
I |
510.3 |
I |
510.4 |
I |
| Vibration |
514.2 |
VIII, X |
514.3 |
I |
514.4 |
I |
514.4 |
I |
| Shock |
516.2 |
I, II, V |
516.3 |
I, IV |
516.4 |
I, IV |
516.5 |
I, IV |
Measurements made in accordance with EIA-152C/204D, TIA-603.
All stated specifications are subject to change without notice or obligation.
OPTIONS
- BC-119N DESKTOP CHARGER
AD-105 DESKTOP CHARGER ADAPTER
BC-145/UK AC ADAPTER
Rapidly charges installed Ni-Cd battery cell assembly, BP-202. The charger adapter and the AC adapter supplied with the BC-119N depending on version. Charging time: 75 to 85 min.
- BP-226 BATTERY CASE
AA (LR6)×5 alkaline cells. BP-226 is Water-resistant, equivalent to JIS Grade 4.
- BP-227 Li-Ion BATTERY PACK
7.2V/1700mAh. Provides 10 hours operating time* (approx.).
Operating temp. range: –20°C to +60°C; –4°F to +140°F.
* Tx: Rx: standby=5:5:90.
- BC-152 DESKTOP CHARGER + BC-147A/E AC ADAPTER
Regularly charges the BP-227 in 9–10 hours.
- BC-119N DESKTOP CHARGER + AD-100 CHARGER ADAPTER + BC-145A/E/V AC ADAPTER
Rapidly charges the BP-227 in 2.5–3 hrs.
- BC-121N MULTI-CHARGER + AD-100 CHARGER ADAPTER + BC-157 AC ADAPTER
Rapid charges up to 6 battery packs (Six AD-100s are required) in 2.5–3 hours.
OPC-656 DC POWER CABLE; For use with the BC-121. (12–20V DC required).
- HM-138 SPEAKER-MICROPHONE
Full sized, waterproof construction corresponds to JIS Grade 7. (1 m/30 min.).
- MB-86 BELT CLIP
Swivel type. Prevents accidental dropping from your belt.
- MB-98 BELT CLIP
Alligator type. Same as supplied.
- MB-96F LEATHER BELT HANGER
Leather belt hanger. For use with MB-98.
- CP-17L CIGARETTE LIGHTER CABLE
- OPC-515L DC POWER CABLE
For use with the BC-152 or BC-119N. (12–16V DC required)
- OPC-966 INTERFACE CABLE
RS-232C interface cable for connecting with a PC.
- ANTENNAS
FA-S24V 136–150MHz (Blue ring)
FA-S59V 150–174MHz (Red ring)
FA-S27U 400–470MHz (Green ring)
FA-S56U 450–520MHz (Red ring)
FA-S74U 490–520MHz (Blue ring)
